Description Of Air Separation Plant - KDO

Air Separation Plant - KDO Specificaton & Trade Terms

Place Of OriginChina
Price TermEX-Work
Payment TermT/T
Do not use cooling water, The ability to adapt is good.; Donít require Complex installation process, just a simple connection.; Complete equipment is easy to move to another area operations.
Main technique target of Air Separation Plant- Nitrogen Generator-Liquid Nitrogen Plant:
Products Capacity (m≥/hr) Purity (%) Pressure (Mpa)
Oxygen 50-2000 99.6-99.8 0.25-22
Liquid Oxygen Right amount 99.6-99.8 0.25
Nitrogen 50-3000 99.99-99.999 0.5-22
Liquid Nitrogen Right amount 99.99-99.999 0.5-1.1

We can provide the special designs as the user requires.
Main equipment of Air Separation Plant- Nitrogen Generator-Liquid Nitrogen Plant:
1.Air compressor 2. Air tank 3.Precision filter
4.Air pre-cooling system 5.Water separator
6.Molecular sieve purification system
7.Heater or molecular sieve purification system
8.Rectification column 9.Heater or the rectification column
10.Gas bearing turbo-expander 11.Liquid Oxygen Pump
12.Filling device 13.Electrical & instrument control system
14.Liquid storage tanks 15.Gas cylinders, etc
Main Features of Air Separation Plant- Nitrogen Generator-Liquid Nitrogen Plant:
* This development and design of flow is new, my company use the technology to mature.
* Simple operation, convenient maintenance, starting time is short, unit power consumption is low.
* Oxygen of high purity and very stable, meet and exceed technical indicators of GB8982-1998
* Use of air cooling equipment, do not need cooling water, adaptable, saving the cost.
*Security:The outside compression process is oxygen be compressed atroom temperature, The inside compression process is liquid oxygen be compressed at low temperature, Security than more with the inside compression process; Extraction a lot of liquid oxygen from evaporation-condenser, To ensure that no accumulation of hydrocarbons; Evaporation of high pressure with liquid oxygen, reducing the possibility of hydrocarbon accumulation; Reducing fire hazards.
* Reliability: liquid oxygen pump excellent performance, easy to maintain; Booster compressor is one or two compression, oxygen compressor Booster compressor is three or five compression, High reliability with booster compressor.
